GMS Steel Fabrications Ltd - Enclosed Skips
GMS Standard skip ranges from 2yd up to 16yd
Various design options and extras available
-
Flat top
-
Scow Ends
-
Single tip
All our skips come as standard with
-
Forged lifting lugs with backing plates
-
Floor angles
-
Corner gussets
-
Fully welded external seams, stitched channels
-
Weld I.D.
-
Stacking blocks
-
Reflective markerboards & protectors
-
Drain holes
Enclosed Skip - 6 Yard
CONTAINER SPECIFICATIONS
BASE
4mm mild steel plate
SIDES & ENDS
4mm mild steel plate ends, 3mm mild steel sides & roof.
LIDS
3mm Dimond pressed lids OR DURAFLEX® plastic lids
REINFORMENT
RSC76mm x 38mm x 6.7kg/metre – SINGLE RAIL on SIDES
LIFTING LUGS
4 no Shepperd Meiler type manufactured skip lugs welded through both the channels and side plates
TIPPING BARS
30mm mild steel tipping bar with FLT6mm pressed plate supports – EACH END
Optional Extras #1
6 CUBIC YARD
Click On Icon To
Download Specification Sheet
Enclosed Skip - 8 Yard
CONTAINER SPECIFICATIONS
BASE
4mm mild steel plate
SIDES & ENDS
4mm mild steel plate ends, 3mm mild steel sides & roof.
LIDS
3mm Dimond pressed lids OR DURAFLEX® plastic lids
REINFORMENT
RSC76mm x 38mm x 6.7kg/metre – SINGLE RAIL on SIDES
LIFTING LUGS
4 no Shepperd Meiler type manufactured skip lugs welded through both the channels and side plates.
TIPPING BARS
30mm mild steel tipping bar with FLT6mm pressed plate supports – EACH END
Optional Extras #1
8 CUBIC YARD
Click On Icon To
Download Specification Sheet
Enclosed Skip - 10 Yard
CONTAINER SPECIFICATIONS
BASE
4mm mild steel plate
SIDES & ENDS
4mm mild steel plate ends, 3mm mild steel sides & roof.
LIDS
3mm Dimond pressed lids OR DURAFLEX® plastic lids
REINFORMENT
RSC76mm x 38mm x 6.7kg/metre – SINGLE RAIL on SIDES
LIFTING LUGS
4 no Shepperd Meiler type manufactured skip lugs welded through both the channels and side plates
TIPPING BARS
30mm mild steel tipping bar with FLT6mm pressed plate supports – EACH END
Optional Extras #1
10 CUBIC YARD
Click On Icon To
Download Specification Sheet
Enclosed Skip - 12 Yard
CONTAINER SPECIFICATIONS
BASE
4mm mild steel plate
SIDES & ENDS
4mm mild steel plate ends, 3mm mild steel sides & roof.
LIDS
3mm Dimond pressed lids OR DURAFLEX® plastic lids
REINFORMENT
RSC76mm x 38mm x 6.7kg/metre – SINGLE RAIL on SIDES
LIFTING LUGS
4 no Shepperd Meiler type manufactured skip lugs welded through both the channels and side plates
TIPPING BARS
30mm mild steel tipping bar with FLT6mm pressed plate supports – EACH END
Optional Extras #1
12 CUBIC YARD
Click On Icon To
Download Specification Sheet
Enclosed Skip - 14 Yard
CONTAINER SPECIFICATIONS
BASE
4mm mild steel plate
SIDES & ENDS
4mm mild steel plate ends, 3mm mild steel sides & roof.
LIDS
3mm Dimond pressed lids OR DURAFLEX® plastic lids
REINFORMENT
RSC76mm x 38mm x 6.7kg/metre – SINGLE RAIL on SIDES
LIFTING LUGS
4 no Shepperd Meiler type manufactured skip lugs welded through both the channels and side plates
TIPPING BARS
30mm mild steel tipping bar with FLT6mm pressed plate supports – EACH END
Optional Extras #1
14 CUBIC YARD
Click On Icon To
Download Specification Sheet
Enclosed Skip - 16 Yard
CONTAINER SPECIFICATIONS
BASE
4mm mild steel plate
SIDES & ENDS
4mm mild steel plate ends, 3mm mild steel sides & roof.
LIDS
3mm Dimond pressed lids OR DURAFLEX® plastic lids
REINFORMENT
RSC76mm x 38mm x 6.7kg/metre – SINGLE RAIL on SIDES
LIFTING LUGS
4 no Shepperd Meiler type manufactured skip lugs welded through both the channels and side plates
TIPPING BARS
30mm mild steel tipping bar with FLT6mm pressed plate supports – EACH END
Optional Extras #1
16 CUBIC YARD
Click On Icon To
Download Specification Sheet
